45LS7N

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name45LS7N
Application fieldReproduction on display letters, numbers and symbol from internal matrix and image by focused beam.
Envelopeglass with outputs on ballon
Mass, kg10
Beam focusingelectrostatic
Coloryellow-green
Beam deflectionmagnetic
Brightness, kd/sq.m25nit
