TH4B-1

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTH4B-1
ApplicationFormation of a sawtooth voltage in TV scan modules
EnvelopeGlass, miniature
Mass4
Ignition voltage, V320
Anode-cathode voltage, V116-140
Grid-Cathode voltage, V135-145
