TH4B

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTH4B
ApplicationLow-power sygnal conversion
EnvelopeGlass, miniature
Mass4
Anode-cathode voltage, V125
Direct anode voltage, V225
Max.anode current, mA7,0-70
Average anode current, mA3,5
Grid-Cathode voltage, V100
