TH8G

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTH8G
Applicationas logic element 2*and
EnvelopeGlass, miniature
Mass6
Direct anode voltage, V285
Max.anode current, mA400
Average anode current, mA8
Grid-Cathode voltage, V100-130

See also

MTH90 TH11G Direct anode voltage, V200 TH12G Direct anode voltage, V250 Max.anode current, mA100 TH13G Direct anode voltage, V220 Max.anode current, mA5 TH16B Max.anode current, mA5 Average anode current, mA1 TH17A Direct anode voltage, V180-260 Max.anode current, mA5 TH18A TH19a Max.anode current, mA5 Average anode current, mA1 TH2 TH3B Direct anode voltage, V175 Max.anode current, mA7
