16LM4G

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name16LM4G
ApplicationImage
Envelopeglass, side anode
Mass, g1000
Deflection typeelectromagnetic
Resolution, lines or focused line size, mm0,4mm
Filament voltage, V6,3
Anode voltage, kV20
Afterglow time/colorwith erasing device
