TG4-0,1/1,3

Check availability
SG2S pin diagram
Click to see in full size
NameTG4-0,1/1,3
Application fieldin rectification and relay mode in special equipment
Cathode typeOxide, indirect heating
EnvelopeGlass, miniature
Mass, g20
Filament voltage, V6,3
Filament current, A0,54-0,66
Ignition voltage, V30
A-C voltage, V11
Max.average cathode current, A0,1
Grid voltage, Vminus 7
Max.reverse voltage, kV1,3
