TR1-6,5/15

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTR1-6,5/15
Application fieldin controlled powerful rectifier
Cathode typeOxide, indirect heating
EnvelopeMetal
Mass, g1300
Filament voltage, V5
A-C voltage, V18
Max.average cathode current, A6,5
Grid voltage, Vminus20-plus10
Max.reverse voltage, kV15
