TR2-40/15

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTR2-40/15
Application fieldin controlled powerful rectifier
Cathode typeOxide, indirect heating
EnvelopeMetal
Mass, g7000
Filament voltage, V5
Filament current, A40-55
A-C voltage, V18
Max.average cathode current, A40
Grid voltage, Vminus20-plus10
Max.reverse voltage, kV15
