SG204K

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameSG204K
TypeGas stabilizer
Cathode typecold
Envelopemetal-ceramic
Fillingneon-argon
Stabilized voltage, V160-168,5
Ignition voltage, V200
Current, mA1,0-10,0
Voltage recurrence, V0,1
Noise, mV20/10,0
Ready time1sec
