SG306K

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameSG306K
TypeGas stabilizer
Cathode typecold
Envelopemetal-ceramic
Fillinghydrogen
Mass, g530
Stabilized voltage, V24000-26000
Current, mA0,05-1,5
Voltage recurrence, V125

See also

SG13P Stabilized voltage, V143-155 Current, mA5,0-30,0 SG15P-2 Stabilized voltage, V102-110 Current, mA5,0-30,0 SG16P Stabilized voltage, V79,5-85 Current, mA5,0-30,0 SG17S Stabilized voltage, V850-950 Current, mA10,0-60,0 SG18S Stabilized voltage, V950-1050 Current, mA10,0-60,0 SG19S Stabilized voltage, V1050-1150 Current, mA10,0-60,0 SG1P Stabilized voltage, V143-155 Current, mA5,0-30,0 SG1P-EV Stabilized voltage, V143-155 Current, mA5,0-30,0 SG201S Stabilized voltage, V86-92 Current, mA4,0-15,0 SG202B Stabilized voltage, V81-86 Current, mA1,5-5,0
