OV-12

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameOV-12
Application fieldapplication as signal source in measuring equipment
Cathode typeimpregnated, indirect heating
Output typewaveguide
Envelopemetal-ceramic, with permanent magnet
Mass5kg
Cooling methodforced air
Frequency range5,6-6,0cm
Output power8mw
Filament voltage, V5
Filament current, A2
First anode voltage, V100-400
Slow-wave circuit voltage, V500-1450

See also

OV-1 Frequency range2,95-4,6cm Output power15mW OV-13 Frequency range3,7-5,7cm Output power5mW OV-14 Frequency range3,0-3,8cm Output power5mW OV-19 Frequency range10170-6530MHz Output power25mW OV-2 Frequency range4,4-6,8cm Output power20mW OV-20 Frequency range6980-4420MHz Output power45mW OV-21 Frequency range1,5-1,66cm Output power0,5mW OV-22 Frequency range1,65-2,55cm Output power1,2mw OV-24 Frequency range1,14-1,67cm Output power1mW OV-30 Frequency range0,8-1,16cm Output power1mW
