OV-21

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameOV-21
Application fieldapplication in measuring equipment
Cathode typeimpregnated, indirect heating
Output typewaveguide
Envelopemetal-ceramic, with permanent magnet
Mass12,7kg
Cooling methodforced water
Frequency range1,5-1,66cm
Power irregularity in frequency band, dB14
Output power0,5mW
Filament voltage, V6,3
Filament current, A2
Slow-wave circuit voltage, V1500-3000
