OV-47

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameOV-47
Application fieldapplication as electronically tunable UHF source
Cathode typealloy, direct heating
Output typewaveguide
Envelopemetal-ceramic, with permanent magnet
Mass1,1kg
Cooling methodconductive
Frequency range5,45-8,31cm
Power irregularity in frequency band, dB8
Output power10m
Filament voltage, V1,2
Filament current, A2,8
Slow-wave circuit voltage, V350-1200
