NameOV-604
Application fieldapplication as electronically tunable heterodyne and low-power generator in measuring equipment
Cathode typeoxide, sintered, indirect heating
Output typecoaxial
Envelopemetal-glass, with permanent magnet
Mass4,5kg
Cooling methodnatural
Frequency range2725-1540MHz
Power irregularity in frequency band, dB14
Output power40mW
Filament voltage, V6,3
Filament current, A1,3-1,8
First anode voltage, V60-180
Slow-wave circuit voltage, V170-1300
External loading agreement coefficient1,7
