NameOV-605
Application fieldapplication as electronically tunable heterodyne and low-power generator in measuring equipment
Cathode typeoxide, sintered, indirect heating
Output typecoaxial
Envelopemetal-glass, with permanent magnet
Mass12kg
Cooling methodnatural
Frequency range18-36cm
Power irregularity in frequency band, dB12
Output power30mW
Filament voltage, V12,6
Filament current, A0,6-1,0
First anode voltage, V30-70
Slow-wave circuit voltage, V120-760
External loading agreement coefficient1,6
