NameOV-611
Application fieldapplication as electronically tunable heterodyne and low-power generator in measuring equipment
Cathode typeoxide, sintered, indirect heating
Output typecoaxial
Envelopemetal-glass, with permanent magnet
Mass15kg
Cooling methodnatural
Frequency range1000-488MHz
Power irregularity in frequency band, dB8
Output power200mW
Filament voltage, V12,6
Filament current, A1,5
First anode voltage, V30-80
Slow-wave circuit voltage, V400
External loading agreement coefficient1,6
