NameOVS-5
Application fieldapplication as heterodyne in special equipment
Cathode typeimpregnated, indirect heating
Output typewaveguide
Envelopemetal-ceramic
Mass325g
Cooling methodnatural
Frequency range3,1-3,3cm
Power irregularity in frequency band, dB3,5
Output power30mW
Tuning steepness2,5-8,0MHz/V
Filament voltage, V6,3
Filament current, A0,6
Collector voltage, V165
External loading agreement coefficient1,5
