RR-140

Check availability
SG2S pin diagram
Click to see in full size
NameRR-140
Typewide-band
Application fieldMixing detector protection
Mass150g
Frequency range2,81-2,96cm
Pulse power300W
Full power50mW
Pulse repeating frequency1000Hz
External loading agreement coefficient1,5
Relax time8uS
Pulse duration1uS
