GSh-6

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameGSh-6
Application fieldReceiver noise coefficient measurement
Cathode typedirect heating
Envelopeglass
Fillingneon
Mass20g
Frequency band0,57-1,18cm
Filament voltage, V6,3
Filament current, A0,4-0,55
Ignition voltage0,8-2,0kV
Anode voltage, V175-210
Anode current, A0,06
Tolerance, %10
External loading agreement coefficient1,25
