RR-49M

Check availability
SG2S pin diagram
Click to see in full size
NameRR-49M
TypeHi-Q resonant
Application fieldMixing detector protection
Envelopemetal
Mass135
Frequency range3,1-3,5cm
Pulse power300kW
Full power25mW
Pulse repeating frequency1000
Pulse duration0,35-2,00
