RR-5

Check availability
SG2S pin diagram
Click to see in full size
NameRR-5
TypeHi-Q resonant
Application fieldRadar receiver protection from Hi-power pulses
Envelopeglass
Mass25g
Frequency range3093-2913MHz
Pulse power250kW
Full power55mW
Relax time10uS
Pulse duration1uS

See also

RR-1 Frequency range3179-3309MHz Pulse power1000kW RR-140 Frequency range2,81-2,96cm Pulse power300W RR-141 Frequency range912MHz Pulse power7-10kW RR-142 Frequency range1912MHz Pulse power7kW RR-143 Frequency range1912MHz Pulse power100mW RR-15-1 Frequency range0,803-0,827cm Pulse power20-30kW RR-2 Frequency range2939-3059MHz Pulse power1000kW RR-20 Frequency range3056-3162MHz Pulse power1000kW RR-200 Frequency range3,17-3,23cm Pulse power50kW RR-23 Frequency range0,803-0,827cm Pulse power20-30kW
