RR-81

Check availability
SG2S pin diagram
Click to see in full size
NameRR-81
Typewide-band
Application fieldapplication in antenna switch to protect receiver from transmitter pulses
Envelopemetal
Mass1,1kg
Frequency range553-587MHz
Pulse power250kW
Full power850W
Pulse repeating frequency375Hz
External loading agreement coefficient1,4
Relax time40uS
Pulse duration3uS
