K-147

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameK-147
TypeReflex
Application fieldin measuring equipment
Cathode typeindirect heating
Envelopemetal-ceramic, coaxial output
Mass22g
Cooling methodNatural
Frequency band7,9-13,2GHz
Output power32mW
Tuning steepness, MHz/mA1,5
Tuning range, MHz5
Filament voltage, V6,3
Filament current, A0,45-0,6
Resonator voltage, V350
Reflector negative voltage, V20-600
