K-152

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameK-152
TypeReflex
Application fieldapplication as heterodine in special equipment
Cathode typeindirect heating
Envelopemetal-ceramic, waveguide output
Mass200g
Cooling methodforced air
Frequency band32600-31680MHz
Output power20mW
Tuning steepness, MHz/mA1,5-6,0
Tuning range, MHz60
Filament voltage, V6,3
Filament current, A0,2-0,7
Resonator voltage, V500
Reflector negative voltage, V50-300
