M-104

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameM-104
Typecontinous working
Application fieldapllication in medical equipment and industrial heating and drying
Envelopemetal-ceramic
Mass, kg3
Cooling methodforced air
Frequency range1st 933,3/2nd 896,7
Output power200W
Filament voltage, V7
Filament current, A6,5
Anode voltage, kV2,5
External loading agreement coefficient1,1
