M-86

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameM-86
Typecontinous working
Application fieldapplication in microwave ovens and heater
Cathode typedirect heating
Envelopemetal-glass-ceramic
Mass, kg3,2
Cooling methodforced air
Frequency range2327,5-2422,5MHz
Output power1kW
Filament voltage, V3,4-4,3
Filament current, A20
Anode voltage, kV3,1-3,9
External loading agreement coefficient4,25
