NameM-32
Typecontinous working
Application fieldApplication as microwave energy source
Cathode typeTungsten, direct heating
EnvelopeMetal, not-batched
Mass, kg2,5
Cooling methodforced water
Frequency range9,5-12,5cm
Output power0,4kW
Frequency pulling, MHz24
Filament voltage, V7,2
Filament current, A15,2-17,5
Anode voltage, kV4,5-5,0
External loading agreement coefficient1,2
