NameM-80
Typecontinous working
Application fieldapplcation as pump generator of parametric amplifier
Cathode typeoxide, indirect heating
Envelopemetal, batched, mechanical tuning
Mass, kg1,6
Cooling methodforced air
Frequency range18675-18525MHz
Output power1W
Frequency pulling, MHz15
Filament voltage, V5,0-5,5
Filament current, A0,2-1,8
Anode voltage, kV0,4-0,55
External loading agreement coefficient1,15
