M-81

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameM-81
Typecontinous working
Application fieldfor industrial heating and drying
Cathode typedirect heating
Envelopenot-batched
Mass, kg6,5
Cooling methodforced water
Frequency range1st 2375-2425 /2nd 2325-2375MHz
Output power5kW
Filament voltage, V10 to 16
Filament current, A28-36
Anode voltage, kV6
External loading agreement coefficient1,1
