NameM-83
Typecontinous working
Application fieldapplication as pump generator of quantum parametric amplifier
Cathode typeoxide, indirect heating
Envelopemetal, batched, mechanical tuning
Mass, kg2
Cooling methodwater
Frequency range58700-58300MHz
Output power2W
Frequency pulling, MHz30
Tuning steepness2MHz/mA
Filament voltage, V6,3
Filament current, A1,0-2,0
Anode voltage, kV1,5-2,0
External loading agreement coefficient1,1
