M-90

Check availability
SG2S pin diagram
Click to see in full size
NameM-90
Typecontinous working
Application fieldapplication in microwave ovens and heater
Cathode typedirect heating
Envelopeglass-ceramic
Mass, kg7
Cooling methodforced air
Frequency range2325-2425MHz
Output power1kW
Filament voltage, V3,4-4,6
Anode voltage, kV3,07-3,53
External loading agreement coefficient4,5
