NameMI-110
TypePulse
Application fieldoscillation of microwave energy
Cathode typeoxide, indirect heating
EnvelopeMetal, not-batched
Mass, kg4,8
Cooling methodforced air
Frequency range575-565MHz
Output power200kW
Frequency pulling, MHz2,5
Filament voltage, V6,3
Filament current, A2,0-2,4
Anode voltage, kV27
External loading agreement coefficient1,1
Pulse duration, uS3
Space factor or pulse repeating frequency0,0006-0,0013
