MI-137

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameMI-137
TypePulse
Application fieldapplication in UHF generators
Cathode typeoxide, indirect heating
Envelopemetal, not-batched
Mass, kg1,9
Cooling methodforced air
Frequency range1765-1800MHz
Output power250W
Frequency pulling, MHz5
Tuning steepness0,15MHz/A
Filament voltage, V12,6
Filament current, A1,86-2,24
Anode voltage, kV22,5-25,2
External loading agreement coefficient1,1
Pulse duration, uS0,7-1,0
Space factor or pulse repeating frequency1000Hz
