NameMI-284
TypePulse
Application fieldapplication in UHF generators
Cathode typeindirect heating
EnvelopeMetal
Mass, kg4,5
Cooling methodforced air
Frequency range14725-14825MHz
Output power80kW
Frequency pulling, MHz22
Tuning steepness1,5MHz/A
Filament voltage, V6,3
Filament current, A4,1-4,9
Anode voltage, kV14-15
External loading agreement coefficient1,5
Pulse duration, uS0,4-1,5
Space factor or pulse repeating frequency0,0002-0,0005
