NameMI-296A
TypePulse
Application fieldapplication in navy radars
Cathode typeimpregnated, indirect heating
Envelopemetal-ceramic
Mass, kg1,55
Cooling methodNatural
Frequency range9305-9355MHz
Output power16kW
Frequency pulling, MHz12
Filament voltage, V5,3-6,3
Filament current, A1,4-1,6A
Anode voltage, kV6,8-7,5
External loading agreement coefficient1,1
Pulse duration, uS0,05-1,0
Space factor or pulse repeating frequency0,00014-0,001
