NameMI-29A
TypePulse
Application fieldoscillation of high-power microwave pulses
Cathode typeoxide, indirect heating, grid-shaped
EnvelopeMetal, not-batched
Mass, kg2,6
Cooling methodforced air
Frequency range3263-3233Mhz
Output power850W
Tuning steepness0,3MHz/A
Filament voltage, V12,6
Filament current, A3,0-3,6
Anode voltage, kV26-30
External loading agreement coefficient1,1
Pulse duration, uS2,5
Space factor or pulse repeating frequency400Hz
