NameUV-12
Application fieldapplication as HF power amplifier
Cathode typeOxide, indirect heating
Output typewaveguide 4x23mm
Envelopeglass with focusing system in metal envelope
Mass850g
Cooling methodnatural
Frequency range3,1-4,1cm
Gain30db
Filament voltage, V6,6
Filament current, A0,3-0,5
Slow-wave circuit voltage, V600-750
External loading agreement coefficient1,7
Noise coefficient400kTo
