NameUV-205
Application fieldUHF power amplification
Cathode typeOxide, indirect heating
Output typewaveguide
Envelopeglass
Mass150g
Cooling methodforced air
Frequency range4400-3400
Output power3-4W
Gain30db
Filament voltage, V6,3
Filament current, A1,0-1,4
First anode voltage, V1100-1350
Slow-wave circuit voltage, V1250-1475
Control electrode voltage, V10,0-5,0
Collector voltage, V1500
External loading agreement coefficient2
Noise coefficientS/N=45dB
