NameUV-22A
Application fieldUHF low-noise amplification
Cathode typeOxide, indirect heating
Output typecoaxial
Envelopeglass
Mass150g
Cooling methodforced air
Frequency range815-720MHz
Gain15dB
Filament voltage, V1,9-2,7
Filament current, A0,5-0,8
First anode voltage, V50
Slow-wave circuit voltage, V125-300
Control electrode voltage, V15
Collector voltage, V425-500
External loading agreement coefficient2
Noise coefficient7,8dB
