SG2S pin diagram SG2S pin diagram
Click to see in full size
NameLI217
TypeImage-orthicon
Application fieldin low illuminating TV equipment
Beam focusingelectromagnetic
Beam deflectionelectromagnetic
Max.spectrum sensitivity, Angstrem4000-5000
Photocathode area, mm24 x 32
Resolution, lines600
Illuminating intensity, Lux5*10e-6-1*10e-2
