LI223

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameLI223
TypeImage-orthicon
Application fieldstudio BW broadcasting
Beam focusingelectromagnetic
Beam deflectionelectromagnetic
Max.spectrum sensitivity, Angstrem4400-5000
Photocathode area, mm24 x 32
Illuminating intensity, Lux1,8
