LI225

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameLI225
TypeImage-orthicon
Application fieldin 625-string TV equipment
Beam focusingelectromagnetic
Beam deflectionelectromagnetic
Max.spectrum sensitivity, Angstrem4500-5250
Photocathode area, mm24 x 32
Resolution, lines625
Illuminating intensity, Lux0,3
