K-29

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameK-29
TypeReflex
Application fieldapplication as low-power generator in special or measuring equipment
Cathode typeOxide, indirect heating
Envelopemetal, coaxial output, without tuning mechanism
Mass250g
Cooling methodheatsink or forced air
Frequency band8810-10340MHz
Output power15mW
Tuning steepness, MHz/mA20MHz/V
Tuning range, MHz30
Filament voltage, V6,3
Filament current, A0,45-0,7
Resonator voltage, V320
Reflector negative voltage, V150-450
