TGI1-2000/35

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTGI1-2000/35
Applicationin special equipment
Envelopemetal-ceramic
Mass6000
Frequency, Hz330
Filament voltage, V6,3
Filament current, A52-59
Pulse anode current, A2000
Average anode current, mA3000
Direct and reverse voltage, kV35
Anode current pulse duration, uS10
