TGI1-2500/35

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTGI1-2500/35
Applicationin special equipment
Envelopeglass
Mass7000
Frequency, Hz250
Filament voltage, V6,3
Filament current, A50-60
Pulse anode current, A2500
Average anode current, mA2500
Direct and reverse voltage, kV35
Anode current pulse duration, uS10
