TGI1-50/6

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTGI1-50/6
Applicationas commutating device
Envelopemetal-ceramic
Mass150
Frequency, Hz1100
Filament voltage, V6,3
Filament current, A3,5-4,8
Pulse anode current, A50
Average anode current, mA120
Direct and reverse voltage, kV6
Anode current pulse duration, uS0,2-4
