TGI3-500/16

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTGI3-500/16
Applicationas commutating device
Envelopemetal-ceramic
Mass800
Frequency, Hz50000
Filament voltage, V6,3
Filament current, A11,0-15,0
Pulse anode current, A500
Average anode current, mA500
Direct and reverse voltage, kV16
Anode current pulse duration, uS0,3-10,0
