TGU1-60/7

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTGU1-60/7
Applicationin special equipment
Envelopemetal-ceramic
Mass700
Frequency, Hz15000-400000
Filament voltage, V6,3
Filament current, A22-28
Pulse anode current, A60
Direct and reverse voltage, kV7
Anode current pulse duration, uS10
