1C1S

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name1C1S
Typerectifier
ApplicationHF pulses rectification
Cathode typeoxide, direct heating
Envelopeglass
Mass, g30
Socket typeRSh5/octal
Filament voltage, V0,7
Filament current, A0,17-0,2
Anode voltage, V50
Max.reverse anode voltage, kV15kV
Anode current, A0,006
Anode power, W0,5
Reverse grid current, uA5
