1C21P

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name1C21P
Typerectifier
Applicationapplication in horizontal scan module
Cathode typeoxide, direct heating
Envelopeglass, miniature
Mass, g22
Socket typersh8
Filament voltage, V1,4
Filament current, A0,65-0,73
Anode voltage, V100
Max.reverse anode voltage, kV25
Anode current, A0,008
